P. 98


                  Pool surrounds
                  Pumps and plumbing extra
                  – see price list.
                  Centrepiece and wall fountains,
                  excluding Haddonstone Wall
                  Plumbing included. Pumps extra
                  – see price list.

                  Self-circulating fountains,
                  including Haddonstone Wall
                  Pumps and plumbing included.
                  Please note:
                  Haddonstone’s plumbing kits   Small Pool Surround C4SKVP
                  do not necessarily produce the   (internal diameter 1780mm, 70”)
                  effects shown in the catalogue.   showing Regency Fountain and
                  Details of standard and special   Pedestal. For standard fountain jet,
                  effect fountain jets are available   see page 101.
                  on request.                   TS  Tech Sheet No. P40

                  Medium Pool Surround C4MKVP (internal diameter 2705mm, 106 ⁄2”) showing Neapolitan Fountain  TS   Tech Sheet No. P30 & P50

                                                                                                        TYPICAL SECTION THROUGH SHALLOW POOL LINER
                                                                                                              FOR C4S & C4HS SMALL POOLS
                                                                                                        Liner capacity when filled to maximum water level:
                                                                                                        X400  Small Pool   910 lts  (240 US gallons)
                                                                                                        X430  Half Pool   425 lts  (112 US gallons)
                                                                                                        X410  Small Pool (shallow)  680 lts  (180 US gallons)
                  TYPICAL SECTION THROUGH C4M, C4L, C4XL & C4XXL POOLS  TYPICAL SECTION THROUGH C4S & C4HS SMALL POOLS  X425  Half Pool (shallow)   340 lts  (90 US gallons)

           98                                                                               For details of centrepiece fountains, see pages 90-96
