ARCHITECTURAL STONEWORK

WINDOW SURROUNDS

Haddonstone has a range of classical window surrounds which can be
tailored to suit individual requirements. These surrounds, based on the
Tuscan style, can be used for new build or refurbishment.

Haddonstone will always continue to create custom-made surrounds,
either to an architect’s drawing or to match an existing design. Please
contact your nearest Technical Department for further information.
Window Surround with bespoke Pediment
Window Surrounds also available in TecLite, see page 192.

We strongly recommend that you refer to Eurocode 6 and PD 6697: 2010.

SECTION Bespoke
Pediment
272 (10 11 «16")
Bespoke
Pediment

L380 Cornice

R380 Head

Q381
Head/Jambs 1079
(42 1 ⁄2")

230 (9 1 «16")
P381 Sill
140 650 (25 5 ⁄8")
For Sill Brackets, see page 190. (5 1 ⁄2")
Bull’s-Eye Window Surrounds

Bull’s-Eye Window Surrounds are available in three standard styles, as
illustrated below: Window Surround

890 (35") 166 (6 1 «2") 130
(5 1 «8")

215
(8 7 «16")
96
(3 3 «4") 110 (4 5 «16")
610 (24")
610
(24")
140
(5 1 «2")
122
(4 13 «16")
WS10 WS11 WS12 WS11 (SECTION)

Refer to the Architectural Supplement for specific US designs.
Custom-made products are available on request. 191
