ARCHITECTURAL STONEWORK TECLITE DOOR SURROUNDS

Haddonstone is now able to offer a selection of Door Surround and Door Traditional Door Traditional Door
Canopy designs in the thin-cast GRC/GFRC TecLite material, making
them ideal for retro-fit and plant-on applications. Canopy TLQ335 Surround TLQ330

Alongside these standard designs, Haddonstone is also able to offer a Opening width variable Opening width variable
bespoke service, creating products to your precise requirements. Total weight: 103kg (227 lb) Total weight: 201kg (443 lb)
